Product Overview
The SIGLENT SNA5000A series of Vector Network Analyzers have a frequency range of 9 kHz to 8.5 GHz and 100 kHz to 26.5 GHz, which support 2/4-port scattering parameter, differential-parameter, and time-domain parameter measurements. The SNA5000A series of VNAs are effective instrumentation for determining the Q-factor, bandwidth, and insertion loss of a filter, They feature impedance conversion, movement of measurement plane, limit testing, ripple test, fixture simulation, and adapter removal/insertion adjustments. The VNAs have five sweep types: Linear-Frequency mode, Log-Frequency mode, Power-Sweep mode, CW-Time mode, and Segment-Sweep mode. The SNA5000A series VNAs also support scattering-parameter correction of SOLT, SOLR, TRL, Response, and Enhanced Response for increased flexibility in R&D and manufacturing applications.
| Model | SNA5032A |
| Frequency Range | 100 kHz ~ 26.5 GHz |
| Ports | 2 |
| Dynamic range | 125 dB |
| Trace noise | 0.003dB rms,0.03°rms |
| Range of output level | -55 dBm ~ +10 dBm |
- Frequency range: 9 kHz ~ 8.5 GHz and 100 kHz - 26.5 GHz
- Setting range of output level: -55 dBm ~ +10 dBm
- Dynamic range: 125 dB
- Support 2/4-ports scattering-parameter, differential-parameter, and time-domain parameter measurements
- Support one-key measurement of Q-factor, bandwidth and insertion loss of a filter
- Support impedance conversion, fixture simulation and adapter removal/insertion adjustments
- Optional spectrum analyzer and TDR functions
